High-Precision and Fast Scanning
With high-resolution 3D scanning, we precisely capture the geometry of physical components, accelerating reproduction and design modifications without requiring pre-existing technical drawings.
No file? No problemFrom physical part to CAD model
Why Woodini
Measure, model and make it again.
Part Reproduction and Optimisation
It allows the recreation of worn or discontinued components, enhancing the original design with structural adjustments, modern materials, and optimisations for improved performance and durability.
3D Modelling and CNC Integration
The generated digital models are fully compatible with CAD/CAM software, allowing production using CNC, 3D printing, or other fabrication technologies, ensuring a streamlined and highly accurate workflow.
Decode, recreate, innovate
From physical to digital.
Reverse engineering enables the generation of accurate digital models from physical components, streamlining the reproduction, optimisation, and modification of existing parts.
Leveraging 3D scanning and advanced modelling techniques, this process is perfect for recreating discontinued components, producing customised parts, and enhancing existing designs.
Process
How does the process work?
01
3D Scanning or Manual Measurement
We capture the shape and dimensions of the original part.
02
Digital Reconstruction
We create a precise CAD model compatible with various software platforms.
03
Optimisation and Modifications
The design is adjusted as needed.
Applications
What can we do?
From scanning to the finished part, we handle the whole process.
013D Component Scanning
3D Component Scanning
Precise geometry acquisition of parts with high-resolution 3D scanning systems.
02CAD Model Generation
CAD Model Generation
Scans are converted into fully editable CAD files for engineering and manufacturing applications.
03Discontinued Component Reproduction
Discontinued Component Reproduction
Exact replicas are manufactured for parts no longer available on the market.
04Design Optimisation and Enhancement
Design Optimisation and Enhancement
Dimensions are refined, structures reinforced, and components adapted for new materials or fabrication methods.
05Retrocompatibility and System Integration
Retrocompatibility and System Integration
Models are developed to be fully compatible with existing equipment and systems.
Advantages
Why choose reverse engineering?
01
Component Reproduction Without Original CAD File
Physical objects are converted into fully editable 3D models.
02
Optimisation and Enhancement
Components are modified and perfected to achieve superior performance.
03
Adaptation to New Manufacturing Technologies
Designs are optimised for CNC, 3D printing, and other fabrication methods.
04
Cost Savings
Avoids the need to create entirely new designs, reducing development time and expenses.
Quote
Turn physical parts into digital models!
If you need to recreate, modify, or optimise an existing part, reverse engineering is the ideal solution. Contact us to discover how we can help transform your physical part into a production-ready digital model!
